Equipment

Our machinery

Our machinery is equipped with modern equipment that meets the latest and even highest quality standards to ensure, that we always meet our customer requirements . Below, please find a list of the technical specifications of our machinery park for CNC milling, CNC turning and CNC grinding.

CNC turning and grinding

	Title	Traverse	Specificationen
	DN Solution Puma 3100 LY	Workpiece Ø 420 mm, Z 1.285 mm	4 Axes

	CNC-Video-Messmikroskope MM1	X 300 mm, Y 200 mm, Z 200 mm	with TP 20 – Tastsystem, M3 Software
	Index V160C	Workpiece Ø 310 mm, Z 260 mm	grinding Spindles inside/outside, Material passage 65 mm, Schnaithmann workpiece Up- and unloader equipment, pallet conveyor system with 22 standard pallets
grinding Spindles inside/outside, Material passage 65 mm, Schnaithmann workpiece Up- and unloader equipment, pallet conveyor system with 22 standard pallets
	Tsugami M08SYE	Lathe-Ø 170, Z 330 mm, hollow Spindle Ø 65	Bar feeder Typ FMB, for workpiece Ø 65mm and 3000mm length, turret with Y-axis, main- and counter spindle
Bar feeder Typ FMB, for workpiece Ø 65mm and 3000mm length, turret with Y-axis, main- and counter spindle
	3x Tsugami M08SYE	Lathe-Ø 170,Z 330 mm, hollow Spindle Ø 65 mm	turret with Y-axis, main- und counter spindle
turret with Y-axis, main- und counter spindle
	GE42 INDEX	Ø 225, Z 662	rod loader, max. 42 mm
rod loader, max. 42 mm
	Doosan 310	Ø 250, Z 400	tailstock, admission 65 mm
tailstock, admission 65 mm
	Doosan S310SM	Ø 250, Z 100	reverse conditioning, driven tools
reverse conditioning, driven tools
	Doosan S550L	Ø 420, Z 600	tailstock, back stay
tailstock, back stay
	Doosan S700	Ø 650, Z 2000	tailstock, back stay
tailstock, back stay
	Doosan S310 SMLY	Ø 310 reverse Ø 160 passage way 65	max. length of part: 600mm y-axis: 70mm
max. length of part: 600mm y-axis: 70mm
	DMG CTX Beta 800	turning- Ø 250 Z 800 rod- Ø 85	reverse conditioning, C + Y- axis with driven tools

CNC milling

	Bezeichnung	Verfahrwege	Specification
	NEW 2023: GROB 440 – 4- Achs BAZ	X- Achse 800 mm Y-Achse 800 mm Z-Achse 800 mm	modernes, multifunktionales und interaktives Maschinenpult GROB Pilot mit Siemens SINUMERIK 840 D
	Hedelius C60	X 2000 Y 620 Z 520 B-axis NC
	CNC-Milling Machine Bridgeport	X800 Y500 Z500 B-axis 1º	–

	CNC – BAZ matec – 30 HV	x 3000 y 800 z 1100/horizontal z 1000/vertical 1 axis NC rotary head	CNC-rotary table 630/80
CNC-rotary table 630/80
	DN Solutions DNM 4500	X – 800 mm Y – 450 mm Z – 510 mm	CNC – BAZ with 3 axes
CNC – BAZ with 3 axes
	DN Solutions DVF 5000 (2nd Gen.)	X – 650 mm Y – 520 mm Z – 480 mm B/C 140° (-30/+110)/360°	CNC – BAZ with 5 axes
CNC – BAZ with 5 axes

CNC grinding

	Title	Traverse	Specification
	Precision cross grinding machine SUNNEN MBC 1804	Ø 95
	flat grinding machine TOS Hostivar	X 600 Y 250
	round grinding machine SU	X 200 Z 630
	semi automatic round sanding machine 3Y144 MB	max. Ø: 400mm max. length: 2000mm

CNC sawing

	Title	Treatment	Specification
	NC saw automat Forte	530	NC saw automat Forte
	band saw Forte	250
	horizontal saw automat BEKA-MAK BMSY 1100	1100	horizontal saw automat BEKA-MAK BMSY 1100
reverse conditioning, C + Y- axis with driven tools
	FORTE SBA – Horizontal columns – metal band saw	-> Ø 360 mm

Lapping, honing and eroding

	Title	Traverse	Specification
	Lapping machine Wolters AL00
	Honing machine Sunnen 1801
	Eroding machine AGIETRON EMS 15

Measuring & Testing

	Title	Traverse	Specification
	CNC-Video-Messmikroskope MM1	X 300 mm, Y 200 mm, Z 200 mm	with TP 20 – Tastsystem, M3 Software
	Roundness measuring test site MarSurf XC2	X and Y 25mm table area 200 x 200

	type measuring test site MarForm MMQ 400-2	MarForm MMQ 400-2, motor-driven mould alignment of tilting table Ø 285, Z = 500 X = 280	Roughness measurement PHT 6-350
Roughness measurement PHT 6-350
	CNC-coordinates reading instrument Thome Sigma Plus	X 1500 Y 800 Z 800

	CNC 3-D coordinates reading instruments	Märklen Aberlink AXIOM too SG 900	x 640 y 900 z 500
x 640 y 900 z 500
	Altimeter DIGIMAR CX 1- Mahr	Z600

	Measure profile projector Record 73-1

	roundness measuring instrument RA-116

	outline measuring instrument Contracer CP-200

	tool adjustment Zoller: Venturion 400		Z 600 D 320
Z 600 D 320
	Hardness test HH-401		functions: Rockwell C, Rockwell B, Vickers, Shore
functions: Rockwell C, Rockwell B, Vickers, Shore
	magnetic particle inspection MR 52 Hand yoke MR 98 WAN Brilliant LED, UV Lamp Measuring Instrument UVA/LUX Check Magnetic field strength meter MFM 200.6 Moiety field measuring instrument MP-1		Level 2
Level 2
	Radiation Detector Gamma Scout		measures ionizing radiation
measures ionizing radiation
	Microscop MZM 1		Software COMEF for particle measurement in the range of 0,001 mm
software application: measurement of particulate matter in the range of 0,001 mm
	Zeiss CMM CONTURA – 3-D coordinate measuring machine	X – 700 mm Y – 1000 mm Z – 600 mm
